SD49216DB-HNY | DAHUA - Domo motorizado IP StarLight WizSense | 2 Mpx | Zoom 16x | Leds IR 100 metros | Audio | Alarmas

Cámara

Sensor de imagen

CMOS de 1/2,8"

píxel

2 megapíxeles

máx. Resolución

1920 (H) × 1080 (V)

ROM

128 MB

RAM

256 MB

Velocidad de obturación electrónica

1/1 s–1/30 000 s

Sistema de escaneo

Progresivo

mín. Iluminación

Color: 0,005 lux@F1.6
B/N: 0,0005 lux@F1.6
0 lux (luz IR encendida)

Distancia de iluminación

100 m (328,08 pies) (IR)

Control de encendido/apagado del iluminador

Zoom Prío; Manual; IR inteligente

Número de iluminador

3 (IR)

Lente

Longitud focal

5,0 mm–80,0 mm

máx. Abertura

F1.6

Campo de visión

alto: 53,9°–4,6°; V: 30,3°–2,6°; D: 60°–5,3°

Zoom óptico

16×

Control de enfoque

Auto; Semiautomatico; manual

Distancia de enfoque cercano

0,1 m–2 m (0,33 pies–6,56 pies)

control de iris

Fijado

Distancia DORI

Detectar

Observar

Reconocer

Identificar

1.131 m (3.710,63 pies)

452 m (1482,94 pies)

226 m (741,47 pies)

113 m (370,73 pies)

PTZ

Rango de giro/inclinación

Panorámica: 0° a 360° sin fin
Inclinación: –15° a +90°, giro automático 180°

Velocidad de control manual

Panorámica: 0,1°/s–80°/s
Inclinación: 0,1°/s–80°/s

Velocidad preestablecida

Panorámica: 80°/s; Inclinación: 80°/s

Preestablecido

300

Recorrido

8 (hasta 32 presets por tour)

Patrón

5

Escanear

5

Power-off Memory

Yes

Idle Motion

Pattern; Preset; Tour

PTZ Protocol

DH-SD
Pelco-P/D (auto recognition)

Intelligence

IVS (Perimeter Protection)

Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification

Face Detection

Support face detection; capturing pictures; face enhancement

SMD

YES

Video

Video Compression

H.264H; H.264B; Smart H.265+; H.265; MJPEG (Sub Stream 1); Smart H.264+; H.264M

Streaming Capability

3 streams

Resolution

1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Video Frame Rate

Main stream: 1080p/960p/720p (1–25/30 fps)
Sub stream 1: D1/VGA/CIF (1–25/30 fps)
Sub stream 2: 1080p/960p/720p (1–25/30 fps)

Bit Rate Control

CBR; VBR

Video Bit Rate

H.264: 1792 kbps–8192 kbps
H.265: 512 kbps–5632 kbps

Day/Night

Auto (ICR); Color; B/W

BLC

Yes

WDR

120 dB

HLC

Yes

White Balance

Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

Electronic (EIS)

Defog

Electronic

Digital Zoom

16×

Image Rotation

180°

Privacy Masking

Up to 24 areas can be set, with up to 8 areas in the same view

S/N Ratio

≥55 dB

Audio

Audio Compression

G.711a; G.711Mu; G.722.1; G.726; MPEG2-Layer2; G.729

Network

Network Port

RJ-45 (10/100 Base-T)

Network Protocol

TCP; FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; IP Filter; SMB; HTTP; SSL; DHCP; SMTP; SNMP v1/v2c/v3 (MIB-2); QoS; RTSP; ARP

Interoperability

CGI; Dahua SDK; API; SDK; ONVIF (Profile S&G&T)

Streaming Method

Unicast; Multicast

User/Host

20 (total bandwidth: 64 M)

Storage

FTP; Micro SD card (512 GB); NAS

Browser

IE 7 and later versions
Chrome
Firefox
Safari

Management Software

DSS;  DMSS; ConfigTool; NVR; Smart PSS; IVSS

Mobile Client

iPhone; iPad; iOS; Android

Certification

Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014

Port

Audio Input

1 channel (LINE IN, bare wire)

Audio Output

1 channel (LINE OUT, bare wire)

Alarm I/O

2/1

Audio I/O

1/1

Alarm Linkage

Capture; preset; tour; pattern; recording; alarm digital input; audio; send email

Alarm Event

Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection

Power

Power Supply

12 VDC, 3 A (± 10%)
PoE (802.3at)

Power Consumption

Basic: 12 W
Max.: 20 W (IR light)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to +140 °F)

Operating Humidity

≤95%

Protection

IP66; TVS 6000 V lightning proof; surge protection; voltage transient protection

Structure

Product Dimensions

270.4 mm × Φ160.0 mm (10.65" × Φ6.30")

Net Weight

2.4 kg (5.29 lb)

Gross Weight

3.9 kg (8.60 lb)
